PX Series
PX Series
High-speed mechanical shears designed for production cutting, with capacities up to 12′ x 10 ga and cutting speeds up to 45 strokes per minute.
Overview
Pexto PX Series mechanical shears are designed for high-volume sheet metal cutting applications requiring speed, precision, and durability. An oversized motor and gearbox provide cutting speeds of up to 45 strokes per minute.
Standard features include four-edge high-carbon, high-chrome blades, self-leveling hold-down feet with neoprene inserts, a precision-machined T-slotted table, digital readout with handwheel fine adjustment, and a ball-screw-driven 30″ powered back gauge for fast, accurate material positioning.
The optional Pro Package adds a 5′ squaring arm, two front support arms, a rear-drop air-operated sheet support, and a front-operated powered back gauge with DRO.
The PX Series includes five models with maximum cutting lengths from 52.25″ to 145″. All models are rated for 10 ga mild steel, with stainless steel capacities varying by model.
Choose a Model
Select a model to view the machine and highlight its specifications below.
4-foot mechanical shear with 52.25" maximum cutting length, 10 ga mild steel capacity, 14 ga stainless steel capacity, and cutting speeds up to 45 strokes per minute.
Request Quote for PX410Compare PX Series Models
| Specification | PX410 | PX610 | PX810 | PX1010 | PX1210 |
|---|---|---|---|---|---|
| Mild Steel Capacity | 10 ga / 3.5 mm | 10 ga / 3.5 mm | 10 ga / 3.5 mm | 10 ga / 3.5 mm | 10 ga / 3.5 mm |
| Stainless Steel Capacity | 14 ga / 2.0 mm | 14 ga / 2.0 mm | 14 ga / 2.0 mm | 14 ga / 2.0 mm | 12 ga / 2.7 mm |
| Maximum Cutting Length | 52.25" / 1328 mm | 73" / 1855 mm | 97" / 2464 mm | 121" / 3074 mm | 145" / 3673 mm |
| Back Gauge Range | 30" / 762 mm | 30" / 762 mm | 30" / 762 mm | 30" / 762 mm | 30" / 762 mm |
| Strokes Per Minute | 45 | 45 | 45 | 45 | 45 |
| Hold-Down Feet | 14 | 14 | 14 | 16 | 16 |
| Drive Motor | 10 hp | 10 hp | 7.5 hp x 2 | 7.5 hp x 2 | 10 hp x 2 |
| Weight | 4,000 lbs | 5,000 lbs | 6,900 lbs | 9,200 lbs | 11,600 lbs |
| Dimensions | 48" x 72" x 72" | 48" x 72" x 96" | 48" x 72" x 120" | 48" x 72" x 144" | 48" x 72" x 170" |
On mobile, swipe left or right to compare models.
